Gigabyte · Laptop · 2024
G6X
GIGABYTE Gaming G6X 9KG-43PT864SD. Product type: Laptop, Form factor: Clamshell. Processor family: Intel® Core™ i7, Processor model: i7-13650HX. Display diagonal: 40.6 cm (16"), HD type: WUXGA, Display resolution: 1920 x 1200 pixels. Internal memory: 32 GB, Internal memory type: DDR5-SDRAM. Total storage capacity: 1 TB, Storage media: SSD. On-board graphics card model: Intel® UHD Graphics, Discrete graphics card model: NVIDIA GeForce RTX 4060. Operating system installed: FreeDOS. Product colour: Grey
Get this device repaired
Verified shops on RepairYour.Tech document every repair to the Device Passport — real records, not guesses.
Find a verified shop Specifications
Audio
| Audio system | Dolby Atmos |
| Speaker power | 2 W |
| Built-in microphone | Yes |
| Number of built-in speakers | 2 |
Power
| DC-in jack | Yes |
| AC adapter power | 180 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| USB Type-C charging port | Yes |
| USB Power Delivery (USB PD) | Yes |
Camera
| Front camera | Yes |
| Front camera HD type | HD |
| Infrared (IR) camera | Yes |
| Front camera resolution | 1280 x 720 pixels |
Design
| Colour name | Gunmetal Gray |
| Form factor | Clamshell |
| Product type | Laptop |
| Product colour | Grey |
| Introduction year | 2024 |
| Market positioning | Gaming |
Memory
| Memory slots | 2x SO-DIMM |
| Internal memory | 32 GB |
| Memory clock speed | 4800 MHz |
| Memory form factor | SO-DIMM |
| Internal memory type | DDR5-SDRAM |
| Maximum internal memory | 64 GB |
Battery
| Battery weight | 283 g |
| Battery capacity | 73 Wh |
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 4 |
Display
| HD type | WUXGA |
| Touchscreen | No |
| Colour gamut | 45% |
| Display diagonal | 40.6 cm (16") |
| RGB colour space | NTSC |
| Display resolution | 1920 x 1200 pixels |
| Native aspect ratio | 16:10 |
| Maximum refresh rate | 165 Hz |
Network
| Bluetooth | Yes |
| Antenna type | 2x2 |
| Ethernet LAN | Yes |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Bluetooth version | 5.2 |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Mobile network connection | No |
Storage
| NVMe | Yes |
| SSD capacity | 1 TB |
| SSD interface | PCI Express 4.0 |
| Storage media | SSD |
| SSD form factor | M.2 |
| Optical drive type | No |
| Total SSDs capacity | 1 TB |
| Card reader integrated | No |
| Total storage capacity | 1 TB |
| Number of SSDs installed | 1 |
Graphics
| Discrete graphics card | Yes |
| On-board graphics card | Yes |
| Discrete GPU manufacturer | NVIDIA |
| On-board GPU manufacturer | Intel |
| Discrete graphics card model | NVIDIA GeForce RTX 4060 |
| On-board graphics card model | Intel® UHD Graphics |
| Discrete graphics card memory | 8 GB |
| Discrete graphics memory type | GDDR6 |
| On-board graphics card family | Intel® UHD Graphics |
Keyboard
| Numeric keypad | Yes |
| Pointing device | Touchpad |
| Keyboard backlit | Yes |
| Keyboard backlit zone | 1-zone RGB |
| Keyboard backlit colour | RGB |
Software
| Operating system installed | FreeDOS |
Processor
| Efficient cores | 8 |
| Processor cache | 24 MB |
| Processor cores | 14 |
| Processor model | i7-13650HX |
| Processor family | Intel® Core™ i7 |
| Performance cores | 6 |
| Processor threads | 20 |
| Maximum turbo power | 157 W |
| Processor base power | 55 W |
| Processor cache type | Smart Cache |
| Processor generation | 13th gen Intel® Core™ i7 |
| Processor manufacturer | Intel |
| Processor boost frequency | 4.9 GHz |
| Efficient-core Max Turbo Frequency | 3.6 GHz |
| Performance-core Max Turbo Frequency | 4.9 GHz |
Ports & interfaces
| HDMI version | 2.1 |
| HDMI ports quantity | 1 |
| Combo headphone/mic port | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
