Asus · Networking · 2023
ROG Rapture GT-BE98
ASUS ROG Rapture GT-BE98. Wi-Fi band: Quad-band (2.4 GHz / 5 GHz-1 / 5 GHz-2 / 6 GHz), Top Wi-Fi standard: Wi-Fi 7 (802.11be), WLAN data transfer rate (max): 11529 Mbit/s. Ethernet LAN interface type: 10 Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000,2500,10000 Mbit/s, VPN support: VPN Client L2TP VPN Client Open VPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN.... Security algorithms: SSH, WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPA3-Enterprise, WPA3-PSK, WPS. Product type: Tabletop router, Product colour: Black, LED indicators: LAN, Power, WAN. Cables included: LAN (RJ-45)
Get this device repaired
Verified shops on RepairYour.Tech document every repair to the Device Passport — real records, not guesses.
Specifications
Power
| Output current | 3.33 A |
|---|---|
| Output voltage | 19.5 V |
| AC input voltage | 110 - 240 V |
| Power source type | AC |
| AC input frequency | 50/60 Hz |
Design
| Product type | Tabletop router |
|---|---|
| On/off switch | Yes |
| LED indicators | LAN, Power, WAN |
| Product colour | Black |
Antenna
| Antenna design | External |
|---|---|
| Antennas quantity | 8 |
Network
| VPN support | VPN Client L2TP VPN Client Open VPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard VPN Fusion |
|---|---|
| Ethernet LAN | Yes |
| Media server | Yes |
| Dynamic DNS (DDNS) | Yes |
| Ethernet LAN data rates | 10,100,1000,2500,10000 Mbit/s |
| Support Samba (storage) | Yes |
| Ethernet LAN interface type | 10 Gigabit Ethernet |
| Number of guest networks (5 GHz) | 5 |
| Number of guest networks (2.4 GHz) | 5 |
Features
| Flash memory | 256 MB |
|---|---|
| Internal memory | 2000 MB |
| Processor cores | 4 |
| Built-in processor | Yes |
| Processor frequency | 2600 MHz |
Security
| Firewall | Yes |
|---|---|
| DMZ support | Yes |
| Parental control | Yes |
| System event log | Yes |
| Security algorithms | SSH, WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPA3-Enterprise, WPA3-PSK, WPS |
| MAC address filtering | Yes |
Protocols
| DHCP server | Yes |
|---|
Packaging data
| Package depth | 383 mm |
|---|---|
| Package width | 384 mm |
| Package height | 141 mm |
| Package weight | 4.85 kg |
WAN connection
| Ethernet WAN | Yes |
|---|---|
| SIM card slot | No |
| 3G/4G USB modem compatibility | Yes |
Packaging content
| Warranty card | Yes |
|---|---|
| Cables included | LAN (RJ-45) |
| Quick start guide | Yes |
| AC adapter included | Yes |
Ports & interfaces
| USB port | Yes |
|---|---|
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 6 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
Management features
| Reset button | Yes |
|---|---|
| WPS push button | Yes |
| Wake-on-LAN ready | Yes |
| MU-MIMO technology | Yes |
| Quality of Service (QoS) support | Yes |
Weight & dimensions
| Depth | 350.4 mm |
|---|---|
| Width | 350.4 mm |
| Height | 220.6 mm |
| Weight | 2 kg |
Wireless LAN features
| Modulation | 4096-QAM |
|---|---|
| Wi-Fi band | Quad-band (2.4 GHz / 5 GHz-1 / 5 GHz-2 / 6 GHz) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 7 (802.11be) |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| WLAN data transfer rate (max) | 11529 Mbit/s |
| WLAN data transfer rate (first band) | 1376 Mbit/s |
| WLAN data transfer rate (third band) | 5764 Mbit/s |
| WLAN data transfer rate (fourth band) | 11529 Mbit/s |
| WLAN data transfer rate (second band) | 5764 Mbit/s |
