Asus · Laptop
ProArt Studiobook 16
ASUS ProArt StudioBook 16. Product type: Laptop, Form factor: Clamshell. Processor family: AMD Ryzen™ 9, Processor model: 5900HX, Processor frequency: 3.3 GHz. Display diagonal: 40.6 cm (16"), HD type: WQXGA, Display resolution: 2560 x 1600 pixels. Internal memory: 64 GB, Internal memory type: DDR4-SDRAM. Total storage capacity: 1 TB, Storage media: SSD. On-board graphics card model: AMD Radeon RX Vega 7. Operating system installed: Windows 11 Pro. Product colour: Black
Get this device repaired
Verified shops on RepairYour.Tech document every repair to the Device Passport — real records, not guesses.
Find a verified shop Specifications
Audio
| Audio system | SonicMaster |
| Built-in microphone | Yes |
| Number of built-in speakers | 1 |
Power
| DC-in jack | Yes |
| AC adapter power | 240 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output current | 12 A |
| AC adapter output voltage | 20 V |
| USB Power Delivery (USB PD) | Yes |
Camera
| Front camera | Yes |
| Privacy type | Privacy shutter |
| Privacy camera | Yes |
| Front camera HD type | HD |
| Infrared (IR) camera | Yes |
Design
| Colour name | Star Black |
| Form factor | Clamshell |
| Product type | Laptop |
| Product colour | Black |
| Market positioning | Business |
| Original brand name | ASUS |
Memory
| Memory slots | 2x SO-DIMM |
| Internal memory | 64 GB |
| Memory form factor | SO-DIMM |
| Internal memory type | DDR4-SDRAM |
| Maximum internal memory | 64 GB |
Battery
| Battery capacity | 90 Wh |
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 4 |
Display
| HD type | WQXGA |
| Panel type | IPS |
| Touchscreen | No |
| Colour gamut | 100% |
| LED backlight | Yes |
| Display surface | Matt |
| Display diagonal | 40.6 cm (16") |
| RGB colour space | DCI-P3 |
| Anti-glare screen | Yes |
| Display brightness | 500 cd/m² |
| Display resolution | 2560 x 1600 pixels |
| Native aspect ratio | 16:10 |
| Maximum refresh rate | 120 Hz |
Network
| Bluetooth | Yes |
| Ethernet LAN | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Bluetooth version | 5.0 |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Ethernet LAN data rates | 10,1000,100 Mbit/s |
Storage
| NVMe | Yes |
| SSD capacity | 1 TB |
| SSD interface | M.2, NVMe, PCI Express 3.0 |
| Storage media | SSD |
| Total SSDs capacity | 1 TB |
| Card reader integrated | Yes |
| Total storage capacity | 1 TB |
| Compatible memory cards | SD |
| Number of SSDs installed | 2 |
Graphics
| NVIDIA Max-Q | Yes |
| Discrete graphics card | Yes |
| On-board graphics card | Yes |
| Discrete GPU manufacturer | NVIDIA |
| Discrete graphics card model | NVIDIA GeForce RTX 3070 |
| On-board graphics card model | AMD Radeon RX Vega 7 |
| Discrete graphics card memory | 8 GB |
| Discrete graphics memory type | GDDR6 |
| On-board graphics card family | AMD Radeon Vega Graphics |
Keyboard
| Numeric keypad | Yes |
| Keyboard layout | QWERTY |
| Pointing device | Touchpad |
| Keyboard backlit | Yes |
Software
| Operating system installed | Windows 11 Pro |
Processor
| Processor cache | 16 MB |
| Processor cores | 8 |
| Processor model | 5900HX |
| Processor family | AMD Ryzen™ 9 |
| Processor frequency | 3.3 GHz |
| Processor generation | AMD Ryzen 5000 Series |
| Processor manufacturer | AMD |
| Processor boost frequency | 4.6 GHz |
Ports & interfaces
| HDMI version | 2.1 |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Combo headphone/mic port | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
