Acer · Laptop
Swift 3
Acer Swift 3. Product type: Laptop, Form factor: Clamshell. Processor family: Intel® Core™ i7, Processor model: i7-8550U, Processor frequency: 1.8 GHz. Display diagonal: 35.6 cm (14"), HD type: Full HD, Display resolution: 1920 x 1080 pixels. Internal memory: 8 GB, Internal memory type: DDR4-SDRAM. Total storage capacity: 512 GB, Storage media: SSD. On-board graphics card model: Intel® UHD Graphics 620. Operating system installed: Windows 10 Home. Product colour: Stainless steel
Get this device repaired
Verified shops on RepairYour.Tech document every repair to the Device Passport — real records, not guesses.
Specifications
Audio
| Built-in microphone | Yes |
|---|---|
| Number of built-in speakers | 2 |
Camera
| Front camera | Yes |
|---|---|
| Front camera resolution | 1280 x 720 pixels |
Design
| Form factor | Clamshell |
|---|---|
| Product type | Laptop |
| Product colour | Stainless steel |
Memory
| Internal memory | 8 GB |
|---|---|
| Internal memory type | DDR4-SDRAM |
| Maximum internal memory | 12 GB |
Battery
| Battery capacity | 3320 mAh |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 4 |
Display
| HD type | Full HD |
|---|---|
| Panel type | IPS |
| LED backlight | Yes |
| Display diagonal | 35.6 cm (14") |
| Display resolution | 1920 x 1080 pixels |
| Native aspect ratio | 16:9 |
Network
| Wi-Fi | Yes |
|---|---|
| Bluetooth | Yes |
| Antenna type | 2x2 |
| Ethernet LAN | No |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| WLAN controller model | Intel Dual Band Wireless-AC 7265 |
Storage
| SSD interface | SATA III |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Card reader integrated | Yes |
| Total storage capacity | 512 GB |
| Compatible memory cards | SD |
Graphics
| Discrete graphics card | Yes |
|---|---|
| On-board graphics card | Yes |
| On-board graphics card ID | 0x5917 |
| Discrete graphics card model | NVIDIA® GeForce® MX150 |
| On-board graphics card model | Intel® UHD Graphics 620 |
| Discrete graphics card memory | 2 GB |
| Discrete graphics memory type | GDDR5 |
| On-board graphics card family | Intel® UHD Graphics |
| Maximum on-board graphics card memory | 32 GB |
| On-board graphics card OpenGL version | 4.4 |
| On-board graphics card base frequency | 300 MHz |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card dynamic frequency (max) | 1150 MHz |
Keyboard
| Numeric keypad | No |
|---|---|
| Keyboard layout | QWERTY |
| Pointing device | Touchpad |
| Keyboard backlit | Yes |
Software
| Operating system installed | Windows 10 Home |
|---|---|
| Operating system architecture | 64-bit |
Processor
| Bus type | OPI |
|---|---|
| Stepping | Y0 |
| Tjunction | 100 °C |
| Processor cache | 8 MB |
| Processor cores | 4 |
| Processor model | i7-8550U |
| System bus rate | 4 GT/s |
| Processor family | Intel® Core™ i7 |
| Processor socket | BGA 1356 |
| Processor threads | 8 |
| Processor codename | Kaby Lake R |
| Configurable TDP-up | 25 W |
| Processor frequency | 1.8 GHz |
| Processor generation | 8th gen Intel® Core™ i7 |
| Configurable TDP-down | 10 W |
| Processor lithography | 14 nm |
| Processor manufacturer | Intel |
| PCI Express slots version | 3.0 |
| Processor boost frequency | 4 GHz |
| Processor operating modes | 64-bit |
| PCI Express configurations | 1x2+2x1, 1x4, 2x2, 4x1 |
| Thermal Design Power (TDP) | 15 W |
| Configurable TDP-up frequency | 2 GHz |
| Configurable TDP-down frequency | 0.8 GHz |
| Maximum number of PCI Express lanes | 12 |
Ports & interfaces
| Headphone outputs | 1 |
|---|---|
| HDMI ports quantity | 1 |
| USB 2.0 ports quantity | 1 |
| Combo headphone/mic port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
Processor special features
| Intel 64 | Yes |
|---|---|
| Idle States | Yes |
| Intel TSX-NI | No |
| Intel® OS Guard | Yes |
| Intel® Secure Key | Yes |
| Execute Disable Bit | Yes |
| Processor package size | 42 X 24 mm |
| CPU configuration (max) | 1 |
| Intel Flex Memory Access | Yes |
| Intel Enhanced Halt State | Yes |
| Embedded options available | No |
| Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
| Intel Clear Video Technology | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Thermal Monitoring Technologies | Yes |
| Intel® Smart Response Technology | Yes |
| Intel Trusted Execution Technology | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® My WiFi Technology (Intel® MWT) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel Identity Protection Technology version | 1.00 |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
