Acer · Laptop
Nitro 5
Acer Nitro 5 . Product type: Laptop, Form factor: Clamshell. Processor family: Intel® Core™ i5, Processor model: i5-10300H, Processor frequency: 2.5 GHz. Display diagonal: 39.6 cm (15.6"), HD type: Full HD, Display resolution: 1920 x 1080 pixels. Internal memory: 16 GB, Internal memory type: DDR4-SDRAM. Total storage capacity: 512 GB, Storage media: SSD. On-board graphics card model: Intel® UHD Graphics. Operating system installed: Windows 10 Home. Product colour: Black
Get this device repaired
Verified shops on RepairYour.Tech document every repair to the Device Passport — real records, not guesses.
Specifications
Audio
| Built-in microphone | Yes |
|---|---|
| Number of built-in speakers | 2 |
Camera
| Front camera | Yes |
|---|---|
| Front camera HD type | HD |
| Front camera resolution | 1280 x 720 pixels |
Design
| Form factor | Clamshell |
|---|---|
| Product type | Laptop |
| Product colour | Black |
| Housing material | Plastic |
| Market positioning | Gaming |
Memory
| Memory slots | 2x SO-DIMM |
|---|---|
| Internal memory | 16 GB |
| Memory clock speed | 2933 MHz |
| Memory form factor | SO-DIMM |
| Internal memory type | DDR4-SDRAM |
| Maximum internal memory | 32 GB |
Battery
| Battery capacity | 57 Wh |
|---|---|
| Battery life (max) | 9 h |
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 4 |
Display
| HD type | Full HD |
|---|---|
| Panel type | IPS |
| Touchscreen | No |
| LED backlight | Yes |
| Display surface | Matt |
| Display diagonal | 39.6 cm (15.6") |
| Display resolution | 1920 x 1080 pixels |
| Native aspect ratio | 16:9 |
Network
| Bluetooth | Yes |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Bluetooth version | 5.0 |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| WLAN controller model | Intel Wi-Fi 6 AX201 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Storage
| SSD capacity | 512 GB |
|---|---|
| SSD interface | PCI Express |
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 512 GB |
| Card reader integrated | No |
| Total storage capacity | 512 GB |
| Number of SSDs installed | 1 |
Graphics
| Discrete graphics card | Yes |
|---|---|
| On-board graphics card | Yes |
| Discrete GPU manufacturer | NVIDIA |
| On-board graphics card ID | 0x9BC4 |
| Discrete graphics card model | NVIDIA® GeForce RTX™ 2060 |
| On-board graphics card model | Intel® UHD Graphics |
| Discrete graphics card memory | 6 GB |
| Discrete graphics memory type | GDDR6 |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card base frequency | 350 MHz |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card dynamic frequency (max) | 1050 MHz |
Keyboard
| Numeric keypad | Yes |
|---|---|
| Keyboard layout | QWERTY |
| Pointing device | Touchpad |
| Keyboard language | English, Italian |
| Full-size keyboard | Yes |
| Island-style keyboard | Yes |
Software
| Trial software | Microsoft 365 |
|---|---|
| Windows 11 free upgrade | Yes |
| Operating system language | English, Italian |
| Operating system installed | Windows 10 Home |
| Operating system architecture | 64-bit |
Processor
| Tjunction | 100 °C |
|---|---|
| Processor cache | 8 MB |
| Processor cores | 4 |
| Processor model | i5-10300H |
| System bus rate | 8 GT/s |
| Processor family | Intel® Core™ i5 |
| Processor socket | BGA 1440 |
| Processor threads | 8 |
| Processor codename | Comet Lake |
| Processor frequency | 2.5 GHz |
| Processor cache type | Smart Cache |
| Processor generation | 10th gen Intel® Core™ i5 |
| Configurable TDP-down | 35 W |
| Processor lithography | 14 nm |
| Processor manufacturer | Intel |
| PCI Express slots version | 3.0 |
| Processor boost frequency | 4.5 GHz |
| Processor operating modes | 64-bit |
| PCI Express configurations | 1x16, 2x8, 1x8+2x4 |
| Thermal Design Power (TDP) | 45 W |
| Maximum number of PCI Express lanes | 16 |
Ports & interfaces
| Headphone outputs | 1 |
|---|---|
| HDMI ports quantity | 1 |
| Combo headphone/mic port | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
Processor special features
| Intel 64 | Yes |
|---|---|
| Idle States | Yes |
| Intel® OS Guard | Yes |
| Processor ARK ID | 201839 |
| Intel® Secure Key | Yes |
| Execute Disable Bit | Yes |
| Processor package size | 42 x 28 mm |
| CPU configuration (max) | 1 |
| Intel Flex Memory Access | Yes |
| Embedded options available | No |
| Supported instruction sets | SSE4.1, SSE4.2, AVX 2.0 |
| Thermal Monitoring Technologies | Yes |
| Intel Trusted Execution Technology | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Stable Image Platform Program (SIPP) | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
